Description
Overview
- 2.5 Gbps Networking - 2.5 Gigabit Ethernet reaches blazing-fast data rates up to 2.5 billion bits per second—2.5× faster than standard Gigabit Ethernet. For bandwidth-intensive tasks, whether local data transfer or Internet access, the TX201 is up to the task.†
- Versatile Compatibility - With extreme speed and ultra-low latency, 2.5GBase-T is backwards compatible with Fast Ethernet and Gigabit Ethernet, automatically negotiating between higher and lower speed connections.
- Low-Profile and Full-Height Brackets - In addition to the standard bracket, a low-profile bracket is provided for mini tower computer cases. Customized options give you the flexibility to find a bracket that perfectly fits your board design.
- Comprehensive System Support - Fully compatible with Windows 11/10/8.1/8/7, Windows Servers 2022/2019/2016/2012 R2/2012/2008 R2, Linux.
Specifications
- Standards & Protocols: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3x
- Interface: 1× PCI Express 2.1 x 1, 1× RJ45 Gigabit/Megabit Port
- Network Media: 2.5GBASE-T/1000BASE-T/100BASE-TX
- LED: 2.5 Gbps, 1 Gbps, and 100/10 Mbps Link/Act
- Data Rates: 10Mbps, 100 Mbps, 1 Gbps, 2.5 Gbps for Half-Duplex mode, 20Mbps, 200 Mbps, 2 Gbps, 5 Gbps, for Full-Duplex mode
- Dimensions ( W x D x H ): 120.8 × 98.2 × 21.5 mm
- Flow Control: 802.3x
OTHERS
- Certification: FCC, CE, RoHS
- Package Content: 2.5 Gigabit PCIe Network Adapter (TX201)
- Standard/Low-Profile Brackets
- Quick Installation Guide
- Resource CD
- System Requirements: Windows 11/10/8.1/8/7, Windows Servers 2022/2019/2016/2012 R2/2012/2008 R2, Linux
Warranty
3 Years
